Grade 2 Titanium Foil

Grade 2 titanium foil is one of the most widely used commercially pure titanium materials due to its excellent corrosion resistance, stable mechanical properties and outstanding formability. Manufactured according to ASTM B265 titanium strip and sheet standard, this material is widely used in medical devices, electronic components, chemical processing equipment and precision industrial manufacturing.

Grade 2 pure titanium foil has superior ductility and cost benefits when compared to titanium alloys, and it holds up with trusted performance in harsh environments. Due to its light-weight construction and high resistance to corrosion, it has turned to be a very good material for applications requiring long service life and stable operation.

Our company specializes in precision rolled titanium foil manufacturing and supplies high-quality materials for global customers in the medical, electronics, chemical and energy industries.

Grade 2 belongs to the category of commercially pure titanium. The material contains a high percentage of titanium with very low levels of oxygen, nitrogen, carbon and other interstitial elements. This composition provides excellent corrosion resistance and good mechanical properties while maintaining superior ductility.



titanium foil

grade 2 titanium foil

ultra thin titanium foil

Chemical Composition

Titanium Balance
Oxygen ≤ 0.25%
Iron ≤ 0.30%
Carbon ≤ 0.08%
Nitrogen ≤ 0.03%
Hydrogen ≤ 0.015%

Mechanical Properties

Tensile Strength ≥ 345 MPa
Yield Strength ≥ 275 MPa
Elongation ≥ 20%
Density 4.51 g/cm³

Because of these properties, titanium Grade 2 foil can be stamped or deep drawn into intricate configurations without fracturing, making this plate thickness suitable capacitors manufacturing.

Titanium Foil Specifications
Grade 2 titanium foil is rolled with the required dimensions and tolerances to guarantee thickness uniformity and surface smoothness.

Typical specification range:

Thickness: 0.01 mm – 0.50 mm
Width: 50 mm – 320 mm
Supply form: Coil or sheet

Tolerance could be up to ±0.005 mm for titanium foils ultra thin by thickness.
Bright annealed, polished, electropolished and pickled surfaces are available. Various surface handling can be chosen according to the detailed application.

With high corrosion resistance, high strength to weight ratio and chemical inertness Grade 2 titanium foil is extensively used in many industries.

Medical device components

Titanium is widely recognised as having excellent biocompatibility and corrosion resistance in the physiological environment. Consequently, Grade 2 titanium foil is also used for components of medical devices such as medical sensors, parts of surgical instruments and electronic shielding materials that are applied in medical machines.

For applications requiring medical material standards, the material can also comply with ASTM F67 medical titanium requirements.

Electronics and energy industry

Ultra-thin titanium foil is being widely adopted in high tech electronics and energy applications. Common uses include capacitor plates, battery current collectors, fuel cell parts and electronic shielding components. Titanium foil ensures reliable conductivity along with excellent rust-free properties for longtime easy use in electronic devices.

Chemical processing equipment

Titanium foil is widely used in chemical processing industries because of its exceptional resistance to seawater, chloride environments and various acidic solutions. Common applications include corrosion resistant linings, electrolysis cells, chemical reactors and components for heat exchangers. The titanium surfaces can be ion beam processed for removal of the natural oxide layer if desired however, thicker oxide layers may be browning is more difficult to remove and can substantially improve service life of equipment.

Precision industrial manufacturing

In industrial production, titanium foil is widely used for precision stamped components for aerospace, components for marine application and housings for the high performance instruments. The exceptional formability of Grade 2Titanium makes it possible for manufacturers to create high-strength but light-weight components that can be utilized in the most extreme environments.

We focus on providing reliable titanium materials supported by advanced manufacturing equipment and strict quality control processes.

In addition, our engineering team is also available to offer technical assistance in material specification selection for customers' applications.
All of the products are based on high-quality titanium raw materials and test through chemical composition testing, mechanical property testing and thickness tolerance testing. The mill test certificate can be provided for each consignment to ensure full traceability and compliance with ASTM standards. We can offer you stable delivery and professional packing for international transport under efficient production management and export experience.

1.What are the applications of Grade 2 titanium foil?
These are: medical device parts, electronic products, chemical processing systems and high-precision industrial products. Grade 2 Titanium's excellent ductility enables it to be drawn or spun into thin sections and complex forms without reduction in strength. Due to its life expectancy is longer than of other metals and ignorance of rust, it is widely used in environment that ordinary metals such as stainless steel couldn't be used.

2.Can we customize the size and purity?
Support customized width, length, and thickness, and can provide high-purity titanium foil to meet different industry standards.

3.How long is the delivery cycle for titanium foil?
Regular specifications are available in stock, and customized products are confirmed for delivery based on size and quantity. Production can be prioritized for large quantities.
