Medical Grade Titanium Bar (ASTM F136) For Surgical Implants
Suitable for long-term implantation with minimal risk of rejection or adverse tissue reaction.
High Strength & Lightweight
Offers outstanding mechanical strength while remaining significantly lighter than stainless steel materials.
Extra Low Interstitial (ELI) Composition
Lower oxygen and impurity content improves toughness, ductility, and implant safety.
Superior Corrosion Resistance
Maintains stable performance in body fluid environments and resists corrosion over extended periods.
Precision Machining Capability
Ideal for manufacturing orthopedic implants, dental implants, trauma fixation devices, and surgical instruments with high dimensional accuracy.
Medical implant-grade titanium alloy round bars (ASTM F136, Ti-6Al-4V ELI) are core raw materials specifically developed for surgical permanent implant devices. Unlike conventional Grade 5 industrial titanium bars and ordinary pure titanium bars, they undergo strict control over interstitial elements such as oxygen, nitrogen, and carbon, emphasizing low allergenicity, high toughness, and long-term implant safety. Primarily used for precision machining of orthopedic, neurosurgical, and oral surgical implants, these bars are the preferred medical base material for global high-end surgical device manufacturers.
ASTM F136 Grade 23, designated as ELI low-interstitial titanium alloy for implantation, features a tensile strength of ≥860 MPa, yield strength of ≥795 MPa, and elongation of ≥10%. Compared to standard Grade 5 titanium alloy, it exhibits lower impurity levels, superior fatigue resistance, and reduced metal ion release post-implantation. It has been subjected to high standard ISO13485 biocompatible test, showing no cytotoxicity and long-term stay in human body. Good machinability allows precision machining (such as turning, grinding and milling), and high final product accuracy.
Application Scenarios and Dimensional Parameters
| ASTM Grade | Alloy Type | Diameter | Length | Tolerance | Surface Finish | Application |
|---|---|---|---|---|---|---|
| F136 Gr23 | Ti‑6Al‑4V ELI | 2–20 mm | 50–3000 mm | ±0.04 mm | Polished / Electropolished | Surgical permanent implants |
Orthopedic surgical implants: Φ4–12 mm, suitable for micro bone screws, fixation anchors, and spinal connectors, featuring high strength and fatigue resistance;
Oral Implantology: Φ6–16 mm, suitable for implant bodies and abutment blanks, corrosion-resistant and adapted to masticatory forces;
Precision neurosurgical implantation: Φ2–6 mm, suitable for neural fixation devices and intracranial micro-implants, featuring precise dimensions and high safety;
Customized surgical accessories: Support non-standard diameters, tolerances, and lengths for customization, with options for chamfering and deburring as required, suitable for niche surgical instrument development.
Manufacturer's Core Advantages
Our factory specializes in customized production of ASTM F136 implant-grade titanium rods, utilizing vacuum arc melting furnaces and strictly adhering to medical-grade clean production controls. From raw material melting, precision rolling, straightening, and polishing, we implement a closed-loop quality inspection process. We consistently produce all specifications from 2–20 mm, supporting both small-batch R&D prototypes and large-scale mass production. Customizable options include diameter, length, surface finish, and mechanical properties, with comprehensive MTR material reports and biocompatibility test documentation. These fully meet FDA and CE medical certification requirements, making them suitable for exporting medical devices in international trade.
Why choose us
Medical grade precision customization capability
We specialize in customizing ASTM F136 surgical implant specific titanium rods, supporting non-standard diameter, tolerance, length, and surface treatment adjustments as needed. We can provide electric polishing, precision peeling, and cutting services to the specified length. No minimum order quantity limit, quick delivery of small batch samples, precise matching of personalized size requirements for surgical instrument research and mass production, reducing customer secondary processing losses.
Compliant medical data matching
All products are produced strictly in accordance with ASTM F136 medical standards, with material reports, mechanical testing, and biocompatibility traceability documents provided in both Chinese and English for each batch, which can be directly used for overseas medical device registration. The entire customization process can be traced, and we cooperate with customers to complete the organization of FDA and CE certification materials, reducing their compliance costs when going abroad.
Exclusive medical after-sales technical support
The after-sales team has experience in medical titanium material processing, responds to processing technology inquiries 24 hours a day, and provides guidance on turning, grinding, and heat treatment technology. If there are any issues with size, surface, or material, free returns or exchanges will be provided and shipping costs will be borne. Long term customers can enjoy priority production scheduling and inventory reservation, ensuring stable supply of surgical instruments projects.
